SORAYA
Shading and glazing in one profile
Soraya is a patented wall-side closure system that integrates a shading awning or insect screen and a 10 mm glazed slider into a single aluminium body. It mounts on RGM structures fitted with the Flow post, and equally on existing pergolas, walls and other masonry. This lets it close in transitional spaces while adapting to the building already in place.
About the model
The Soraya casing is built from a 20 cm wide, 13.5 cm high aluminium profile, with the awning end bar and its internal steel ballast retracting out of sight into the cassette. Fabric guidance and tension come from the Mirada system: an extruded PVC profile runs the full height of the guide rail, which is also what gives the wind resistance. The front-opening cassette simplifies roller installation, while the roller-support profile is engineered against unwanted deflection, holding a straight line even across wide spans.
Features
SORAYA
- 01
Aluminium profile, wall-side supplementary closure system
- 02
Patented module: shading awning or insect screen plus a 10 mm glass slider in one body
- 03
Full compatibility with RGM structures fitted with the Flow post
- 04
Also installable on existing pergolas, walls and masonry
- 05
Customisable with the LED Line lighting system
- 06
QUALICOAT / QUALICOAT SEASIDE certified coating
Technical data
Technical data
Size range
150 × 150 cm – 600 × 300 cm
Structure
Aluminium profile, steel ballast, INOX side heads
Cassette
20 cm wide, 13.5 cm high profile, front-opening
Fabric guidance
Mirada system, full-height extruded PVC profile in the rail
Size (min.)
W 150 × H 150 cm (width × height)
Size (max.)
W 600 × H 300 cm (width × height)
Control
1-channel or multi-channel remote
Lighting
LED Line system with power supply kit
Coating
QUALICOAT / QUALICOAT SEASIDE certified
What it is for
- Closing the sides of pergolas and terraces with shading and glazing
- Extending transitional spaces on existing walls, pergolas and structures
- Completing Flow-post RGM structures into a single system
- Wind-resistant, straight-running closure of wide openings
- Weather-protected, openable facade for hospitality and living spaces
Options and accessories
- Shading awning or insect screen within the module
- 10 mm glazed sliding panel
- LED Line lighting with power supply kit
- 1-channel or multi-channel remote
- QUALICOAT / QUALICOAT SEASIDE colours and coating
- Flush, slim end caps with a linear design
Pricing
What it costs
Every pergola is an individual configuration — the price depends on size, equipment and installation conditions:
Price on request
Entry configuration: 150 × 150 cm
We provide the exact price in a personal quote, based on the chosen configuration and an on-site survey. Requesting a quote is free of obligation.
Warranty
The manufacturer covers the product with a 2-year full warranty, 1 year on the motors; a partial warranty decreasing in value applies in years 3–5. Claims are handled through Riczu, in Hungarian.
Let us plan it together
Tell us the site, the planned size and the use. We get back within 1 to 2 working days with a concrete quote or a survey appointment.
